C48 Series
Cinch Numbers
Series Designation
C48 --
Coupling Style
0 -- Threaded
1 -- Bayonet
Shell Style
0 -- Square Flange Receptacle
3 -- Single-Hole Mounting Receptacle
6 -- Straight Plug
Environmental Class
R -- Meets MIL-C-26500 (USAF)
How to Order
C48-0 6 R 22-55 P 6-102
Order Code (Deviations)
100 - Connector With Contacts & Cable Support
102 - Connector Less Cable Support With Contacts
105 - Connector Less Contacts With Cable Support
106 - Connector Less Contacts & Less Cable Support
See order codes for Boeing on page 3-14
Alternate Shell Positions
6, 7, 8, 9, 10 per table on page 3-4
(Omit for normal position)
Contact Style
P -- Pin
S -- Socket
Inser t Arrangements
(See page 3-4)
Shell Size
3
Military Standard Part Numbers
You can use MS* as well as C48
Series part numbers when ordering
C48 Series connectors.
*MS part numbers are supplied less
cable support. If cable support is
desired, it must be ordered separately.
MS24266 R 22 T 55 P 6
Military Designation
MS24264 -- Square-Flange Receptacle
MS24265 -- Single-Hole Mounting Receptacle
MS24266 -- Straight Plug
Environmental Class
R -- Meets MIL-C-26500 (USAF)
Shell Size
8, 10, 12, 14, 16, 18, 20, 22, or 24
8, 10, 12, 14, 16, 18, 20, 22, 24
Alternate Shell Positions
N, 6, 7, 8, 9, Y per table on page 3-4
Contact Style
P -- Pin
S -- Socket
Inser t Arrangements
(See page 3-4)
Coupling Style
T -- Threaded
B -- Bayonet
Part numbers for the contacts and assembly tools are listed on page 3-12.
Call Toll Free: 1 (800) 323-9612
3-3
